Product Details:
|
| Nominal Capacity: | 200Ah | Nominal Voltage: | 3.2v |
|---|---|---|---|
| Internal Impedence: | 0.1~0.5mΩ | Operating Votage: | 2.5V~3.65V |
| Dimension: | 182*71*279mm | Battery Weight: | 5.7kg±0.3kg |
-Qualified
for UN38.3/MSDS ROHS CE TUV UL with high safety
-More
than 2000 cycles under the designed working condition
-Ventiation
slots for better cooling
-Battery
shelle material is flame retardant
-Ideal
for HESS or large-scale energy storage
-High
charge/discharge rates
CALB lithium battery high power LiFePO4 cells --the China Aviation Lithium Battery produces high quality lithium ion phosphate battery for all kinds of lithium cells applications.
Model | CALB-SE200 | |
Nominal Capacity | 200Ah | |
Size | 182*71*279mm | |
Operation Voltage | Charge | 3.65V |
Discharge | 2.5V | |
Internal Resistance | 0.1~0.5mΩ | |
Charging Time | Standard Charge | ~4h |
Fast Charge | ~1h | |
Standard Charge/Discharge | 100A(0.5CA) | |
Shell Material | Plastic | |
Operating Temperature | Charge | 0~45℃ |
Discharge | -20~55℃ | |
Recommended SOC Window | SOC:10%~90% | |
Weight | 5.7kg±0.3kg | |
CALB SE 200 LiFePO4 Battery is one of best 200Ah lithium ion battery with high
power energy.
The
weight is only 5.6kg.with brand new design,the SE200 battey is becoming more and
more popular for electric
vehicles,energy storage and UPS.
Every 200Ah LiFePO4 Battery are qualified and we
provide Test Report to Client for Reference and we provide 3
years
warranty.the real capacity of 200Ah Battery are normaly 6% more
than rated capacity, that's 212Ah average.
