Product Details:
|
| Nominal Capacity: | 530ah | Nominal Voltage: | 3.2V |
|---|---|---|---|
| Internal Impedence: | Operating Votage: | ||
| Dimension: | Battery Weight: |
The CATL 530Ah LiFePO4 battery cell is a high-capacity battery cell that is used for energy storage systems. It is manufactured by Contemporary Amperex Technology Co. Limited (CATL), a Chinese battery manufacturer.
This battery cell has a capacity of 530Ah and a nominal voltage of 3.2V. It is designed to provide high energy density and a long cycle life of more than 8,000 cycles at 70% SOH. The battery cell is also known for its high safety performance and reliability.
The CATL 530Ah Prismatic LiFePO4 battery cell is commonly used in energy storage systems for residential, commercial, and industrial applications. It can be used in conjunction with other battery cells to create larger battery packs with higher capacities.
| Parameter | Specification |
|---|---|
| Standard capacity | 530Ah |
| Nominal voltage | 3.2V |
| Battery internal resistance (1KHz) | 0.17±0.05mΩ |
| Battery weight | 9.3±0.3Kg |
| Battery size (Not including the studs) | Height: 203±0.5 mm Length: 275±0.5 mm Thickness: 73±1.0 mm |
| Cycle life | ≥8000cycles |
| Standard charging voltage | 3.65V |
| Discharge cut-off voltage | 2.5V |
| Standard charging current | 0.5C |
| Max charging current | 1C |
| Standard discharge current | 0.5C |
| Max discharge current | 1C |
| Charging temperature | 0~60°C |
| Discharging temperature | -20~60°C |
