Product Details:
|
| Nominal Capacity: | 30ah | Nominal Voltage: | 3.7V |
|---|---|---|---|
| Internal Impedence: | Operating Votage: | ||
| Dimension: | Battery Weight: |
Ideal for custom battery packs requiring high performance, durability, and safety.
Voltage: 3.67V
Capacity: 30Ah
Internal Resistance: 1.46mΩ (full-tab design)
Max Discharge Current: 120A
Dimensions: 46 × 96.5 mm
Weight: 415g (≈0.91 lbs)
Cycle Life: 1,000+ charge/discharge cycles
Robust Performance:
High-capacity 30Ah output with 120A peak discharge.
Low internal resistance (1.46mΩ) for efficient power delivery.
Extended Lifespan:
1,000+ cycles ensure long-term reliability and cost-effectiveness.
Safety Certified:
Compliant with CE, RoHS, UN38.3, and other international standards.
Custom Assembly Support:
Flexible options for PCB, wiring, and connectors.
Warranty Protection:
Backed by a 1-year warranty for added confidence.
Item | Specifications |
Normal Capacity | 30.0 Ah; 1/3C; 25±2°C, 2.8~4.2 V |
Normal Energy | 110.0Wh; 1/3C, 25±2°C, 2.8~4.2 V |
Nominal Voltage | 3.67V (1/3C) |
Discharge Capacity | ≥30.0 Ah; 25°C, 1/3C, 2.8~4.2 V; |
Discharge Energy | ≥110.0 Wh25°C, 1/3C, 2.8~4.2V |
AC Internal Resistance of BOL Status | ≤1.8mΩ |
DC Internal Resistance of BOL Status | ≤4.0mΩ |
Standard Charge Current | 10Ah (1/3C) |
Standard Discharge Current | 10Ah (1/3C) |
Maximum Continuous Charging Current | 1C; (0%, 90%) SOC |
Cycle Life | 1000 cycle, 25°C, 3.0~4.15 V, 0.5C/0.5C |
Environmental Temp | 0~45°C; Charge Temp |
-20~45°C; Discharge Temp | |
Storage Temp | 0~25°C; 1 Year |
0~45°C; 3 Month | |
-20~55°C; 1 Month | |
Self Discharge Rate@25℃ | First month 0.05 V/ month Followed by 0.03V/ month |
Shipping Voltage Range | 3.5~3.8V |
Multiple Rate Discharge | 25°C, 3C; ≥90% Of 1C Discharge Capacity |
High and Low Temperature Discharge | -20°C, 1C; |
55°C, 1C; | |
Cell Weight (With Insulating Film) | 415±10 g |
Cell Dimension | （46.16±0.15)×(96.50±0.35)mm |
Perfect for energy storage systems, AGVs, electric scooters, e-bikes, two-wheelers, and electric sightseeing vehicles.
