Gotion 3.2V 15Ah 32135 cylindrical lifepo4 battery cell

Product Details:
Place of Origin: China
Brand Name: Gotion
Certification: CE
Model Number: IFR32135
Payment & Shipping Terms:
Retail Price: /
Wholesale Price: Negotiable
Packaging Details: cartons or plywoods
Payment Terms: T/T
Nominal Capacity: 15Ah Nominal Voltage: 3.2V
Internal Impedence: 1.5mΩ<R<3mΩ Operating Votage: /
Dimension: 33.6mm(d) * 139.7mm(h) Battery Weight: 268g

Product Description

Gotion 3.2V 15Ah 32135 cylindrical lifepo4 battery cell



Features:

  • The lifepo4 battery capacity of 15,500mAh

  • Utilizes lithium iron phosphate (LiFePO4) chemistry for enhanced safety, minimizing the risk of explosion or combustion from impacts, overcharging, or short circuits.

  • Enables rapid charging and high-current discharge, supporting continuous discharge at 1C.

  • Boasts a cycle life of 2000 times at 80% Depth of Discharge (DOD).

  • Facilitates efficient charge and discharge cycles.

  • Offers higher energy density compared to lead-acid batteries.

  • Provides faster charging times and reduced self-discharge.



Parameters:


Parameter

Specification

Nominal Capacity

1500mAh

Nominal Voltage

3.2V

AC Resistance

1.5mΩ<R<3mΩ

DC Resistance

<8mΩ

Operating Temperature

Charge: -2055℃

Discharge: -3060℃

Regular charge (Slow charge) Current

3A(0.2C)

Regular charge (Slow charge) Voltage

3.65V

maximum pulse discharge rate/C

4500mA(3C)

Room Temperature Cycle Life

2000times

Dimension

33.6mm(d) * 139.7mm(h)

Weight

268g



Details:



dimension



cycle life
