Product Details:
|
| Nominal Capacity: | 15Ah | Nominal Voltage: | 3.2V |
|---|---|---|---|
| Internal Impedence: | 1.5mΩ<R<3mΩ | Operating Votage: | / |
| Dimension: | 33.6mm(d) * 139.7mm(h) | Battery Weight: | 268g |
The lifepo4 battery capacity of 15,500mAh
Utilizes lithium iron phosphate (LiFePO4) chemistry for enhanced safety, minimizing the risk of explosion or combustion from impacts, overcharging, or short circuits.
Enables rapid charging and high-current discharge, supporting continuous discharge at 1C.
Boasts a cycle life of 2000 times at 80% Depth of Discharge (DOD).
Facilitates efficient charge and discharge cycles.
Offers higher energy density compared to lead-acid batteries.
Provides faster charging times and reduced self-discharge.
Parameters：
Parameter | Specification |
Nominal Capacity | 1500mAh |
Nominal Voltage | 3.2V |
AC Resistance | 1.5mΩ<R<3mΩ |
DC Resistance | <8mΩ |
Operating Temperature | Charge: -20～55℃ |
Discharge: -30～60℃ | |
Regular charge (Slow charge) Current | 3A(0.2C) |
Regular charge (Slow charge) Voltage | 3.65V |
maximum pulse discharge rate/C | 4500mA(3C) |
Room Temperature Cycle Life | 2000times |
Dimension | 33.6mm(d) * 139.7mm(h) |
Weight | 268g |
